Mitsubishi FR-F840-00380-E2-60 Inverter

• Minimum Rated Voltage (V) 380
• Min. Permissible Voltage (V) 323
• Maximum Rated Voltage (V) 500
• Max. Permissible Voltage (V) 550
• Current Type AC
• Phases 3
• Rated Output Current SLD (A) 38
• Rated Output Current LD (A) 35
• Rated Motor Capacity SLD (kW) 18,5
• Rated Motor Capacity LD (kW) 18,5
• Frequency Range (Hz) 0,2–590
• Control Method V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
• Motor Type INDUCTION MOTOR, PM MOTOR
• Integrated EMC Filter YES
• Safe Torque Off (STO) YES
• Regenerative (4Q) NO
• Integrated DC Choke NO
• Display FR-DU08
• Display Type 5 DIGITS LED (12 SEGMENT)
• PLC Function YES
• Program Memory 6K
• Program Memory Unit STEPS
• Integrated Digital Inputs 12
• Digital Outputs (Transistor) 5
• Digital Outputs (Relay) 2
• Integrated Analogue Inputs 3
• Integrated Analogue Outputs 2
• IO Type of Terminal Block SPRING CLAMP
• Expandable YES
• USB 1+1 MINI
• Ethernet Port 1
• Built-In Network CC-LINK IE FIELD NETWORK BASIC, MELSOFT/FA, iQSS, MODBUS/TCP, SLMP, BACNET/IP
• Leakage Current (mA) 35(DELTA) / 2(STAR)
• Power Loss SLD (W) 450
• Power Loss LD (W) 415
• Standby Power Consumption (W) 20
• Protection Class IP20
